75
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWC24QE-D3DNA5E/I GWC24QE-D3DNA1E/I
Product Code CB425N04900 CB419N07200
1 Front Panel 2002248603 20022485 1
2 Filter Sub-Assy 11012007 11012007 2
3 Screw Cover 2425245301 24252453 3
4 Front Case 2002248603 20022486 1
5 Air Louver(Manual) 10512737 10512737 3
6 Helicoid Tongue 26112513 26112513 1
7 Left Axile Bush 10512037 10512037 1
8 Display Board 30565269 30565233 1
9 Rear Case assy 22202570 22202570 1
10 Rubber Plug (Water Tray) 76712012 76712012 1
11 Ring of Bearing 26152025 26152025 1
12 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
13 Cross Flow Fan 10352057 10352057 1
14 Evaporator Support 24212178 24212178 1
15 Evaporator Assy 01100100029 01100100029 1
16 Cold Plasma Generator / / /
17 Wall Mounting Frame 01252229 01252229 1
18 Motor Press Plate 26112515 26112515 1
19 Fan Motor 1501214501 1501214501 1
20 Connecting pipe clamp 26112514 26112514 1
21 Drainage Hose 0523001405 0523001405 1
22 Stepping Motor 1521240212 1521240212 1
23 Crank 73012005 73012005 1
24 Guide Louver 1051273802 10512738 1
25 Axile Bush 10542036 10542036 2
26 Electric Box 2011221102 2011221102 1
27 Terminal Board 4201123303 4201123303 1
28 Electric Box Cover2 2011221001 2011221001 1
29 Main Board 30138000661 30138000661 1
30 Shield Cover of Electric Box 01592140 01592140 1
31 Electric Box Cover 2011220901 2011220901 1
32 Jumper 4202021923 4202021923 1
33 Lower Shield of Electric Box 01592139 01592139 1
34 Electric Box Assy 10000203034 10000203564 1
35 Power Cord / / /
36 Connecting Cable / / /
37 Temperature Sensor 3900031302 3900031302 1
38 Remote Controller 30510475 30510475 1
To Next Page
