Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWC18QD-D3DNA6E/O GWC24QE-D3DNA6E/O
Product Code CB427W01700 CB427W02300
1 Front Grill 01473049 01473049 1
2 Cabinet 01433047P 01433047P 1
3 Axial Flow Fan 10335008 10335008 1
4 Fan Motor 1501506402 1501506402 1
5 Chassis Sub-assy 01700000094P 02803214P 1
6 Clapboard Assy 01233153 01233153 1
7 Compressor and Fittings 00105249G 00105249G 1
8 Inhalation Tube Sub-assy 03833913 03833916 1
9 Discharge Tube Sub-assy 03001300244 03833914 1
10 Valve Support Assy 01715010P 01713098P 1
11 Cut off Valve Assy 1/2 07133774 07133157 1
12 Cut off Valve Sub-Assy 07133204 0713317001 1
13 Valve Cover 22245002 22245002 1
14 Right Side Plate 0130509403P 0130509403P 1
15 Retaining Plate 02115006P 02115006P 1
16 Handle Assy 02113109 02113109 1
17 Wire Clamp 26115004 71010003 1
18 Temperature Sensor 3900030901 3900030901 1
19 Rear Grill 01473043 01473043 1
20 Condenser Assy 01100200338 01100200348 1
21 Coping 01255005P 01255005P 1
22 Motor Support Sub-Assy 01705043 0170512001 1
23 Condenser Support Plate 01173132 01173415 1
24 Left Side Plate 01305093P 01305093P 1
25 Handle 26233053 26233053 1
26 Electric Box Assy 10000100287 10000100295 1
27 Terminal Board 42010255 4201025501 1
28 Electric Box 20113027 20113027 1
29 Main Board 30138000686 30138000674 1
30 Radiator 49010252 49010252 1
31 Insulated Board (Cover of Electric Box) 20113003 20113003 1
Above data is subject to change without notice.
