5
Technical Information
Service Manual
Model
1.GWC24QE-D3DNA6E(LC)
2.GWC24QE-D3DNB4E(LC)
3.GWC24QE-D3DNB2E(LC)
4.GWC24QE-D3DNA5E(LC)
5.GWC24QE-D3DNC2E(LC)
6.GWC24QE-D3DNB8E(LC)
7.GWC24QE-D3DNA1E(LC)
1.GWH24QE-D3DNA6E(LCLH)
2.GWH24QE-D3DNB4E(LCLH)
3.GWH24QE-D3DNB2E(LCLH)
4.GWH24QE-D3DNC2E(LCLH)
5.GWH24QE-D3DNB8E(LCLH)
6.GWH24QE-D3DNA5E(LCLH)
7.GWH24QE-D3DNA1E(LCLH)
Product Code
1.CB427002300 2.CB434001900
3.CB432003000 4.CB425004900
5.CB439000700 6.CB438001700
7.CB419007200
1.CB427002400 2.CB434001400
3.CB432002900 4.CB439001500
5.CB438001800 6.CB425005000
CB425005001 CB425005002
7.CB419007800
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 22000(8630~23200) 22000(8630~23200)
Heating Capacity(Min~Max) Btu/h / 23000(8650~26000)
Cooling Power Input(Min~Max) W 2260(600~27000) 2260(600~27000)
Heating Power Input(Min~Max) W / 2300(610~2750)
Cooling Power Current A 10.03 10.03
Heating Power Current A / 10.20
Rated Input W 2700 2750
Rated Current A 11.98 12.20
Air Flow Volume(SH/H/M/L) CFM 706/647/589/530 706/647/589/530
Dehumidifying Volume Pint/h 4.23 4.23
EER (Btu/h)/W 9.73 9.73
COP (Btu/h)/W / 10.00
SEER 16.00 16.00
HSPF / 9.00
Application Area yd
2
32.29-50.23 32.29-50.23
Indoor Unit
Model of indoor unit
1.GWC24QE-D3DNA6E/I
2.GWC24QE-D3DNB4E/I
3.GWC24QE-D3DNB2E/I
4.GWC24QE-D3DNA5E/I
5.GWC24QE-D3DNC2E/I
6.GWC24QE-D3DNB8E/I
7.GWC24QE-D3DNA1E/I
1.GWH24QE-D3DNA6E/I
2.GWH24QE-D3DNB4E/I
3.GWH24QE-D3DNB2E/I
4.GWH24QE-D3DNC2E/I
5.GWH24QE-D3DNB8E/I
6.GWH24QE-D3DNA5E/I
7.GWH24QE-D3DNA1E/I
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 1/4X32 11/16 Φ4 1/4X32 11/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1250/1100/900/800 1250/1100/900/800
Fan Motor Heating Speed(SH/H/M/L) r/min / 1150/1000/900/850
Output of Fan Motor W 30 30
Fan Motor RLA A 0.32 0.32
Fan Motor Capacitor μF 3 3
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ5/16 Φ5/16
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 33 1/4X1X13 1/2 33 1/4X1X13 1/2
Swing Motor Model MP35CJ MP35CJ
Output of Swing Motor W 2.5 2.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H//M/L) dB (A) 48/44/40/36 48/44/40/36
Sound Power Level(SH/H//M/L) dB (A) 58/54/50/46 58/54/50/46
Dimension (WXHXD) inch 42 7/16X12 13/16X9 11/16 42 7/16X12 13/16X9 11/16
Dimension of Carton Box (LXWXH) inch 45X16 1/8X13 3/16 45X16 1/8X13 3/16
Dimension of Package (LXWXH) inch 45 3/16X16 1/4X13 3/4 45 3/16X16 1/4X13 3/4
Net Weight Ib 34.2 37.5
Gross Weight Ib 41.9 45.2
