Gree GWC36LB-D3NNB2A/O

39
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWC36LB-D3NNB2A/I
Product Code CA433N00800
1 Front Panel Assy 2002215801 1
2 Decorative Strip Sub-Assy / /
3 Stand Bar 2421212001 1
4 Filter Sub-Assy
11122106
2
5 Front Case Sub-assy 20900700005 1
6 Upper Guide Louver 1051216601 1
7 Lower Guide Louver 1051216701 1
8 Axile Bush
10542704
6
9 Air Louver 2 1051216902 2
10 Air Louver 1 1051216802 16
11 Connecting Rod 10582086 2
12 Louver Clamp 26112158 9
13 Step Motor / /
14 Water Tray 2018213802 1
15 Water Tray Assy 00007000006 1
16 Screw Cover
2425200506 4
17 Rubber Plug (Water Tray) 76712012 1
18
Rear Case Sub-Assy 20162027 1
19 Cross Flow Fan 1 10352039 1
20 Bearing Holder Sub-assy
26152028
1
21 Cross Flow Fan 2 10352040 1
22 O-Gasket sub-assy of Bearing 76512051 1
23 Left Evaporator Support 24212041 1
24 Evaporator Assy 01002596 1
25 Wall Mounting Frame
01252398
1
26 Fan Motor 1501212003 1
27 Pipe Clamp 26112071 1
28 Drainage Hose 0523001404 1
29 Cover Plate 2012212402 1
30 Motor Fixed Clip
26112354
1
31 Step Motor 1521210701 1
32 Press Plate(Crank) 26112070 1
33 Crank-guide 10582041 1
34 Upper Crank 10562004 1
35 Lower Crank
10562005
1
36 Step Motor / /
37 Electric Box Assy 10000203125 1
38 Electric Box 20112127 1
39 Capacitor CBB61
3301074713
1
40 Terminal Board
42011233
1
41 Main Board 30135545 1
42 Display Board
30565277
1
43 Electric Box Cover 20102252 1
44 Electric Box Cover
20112044S
1
45 Remote Controller
30510112
1
46 Connecting Cable 4002052318 0
47 Connecting Cable
4002054026
0
48 Temperature Sensor
390000451
1
49 Ambient Temperature Sensor
390000591
1
Above data is subject to change without notice.
