41
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWC36LB-D3NNB2A/O
Product Code CA433W00800
1 Axial Flow Fan 10335014 1
2 Fan Motor 1501506203 1
3 Capacitor 3300008107 1
4 Main Board 30135843 1
5 Capacitor CBB61 3301074714 1
6 AC Contactor 44010256 1
7 Transformer 4311023601 1
8 Terminal Board 4201025801 1
9 Electric Box Assy 10000203124 1
10 Left Side Plate 01305043P 1
11 Top Cover Sub-Assy 01255014 1
12 Motor Support Sub-Assy 01705437 1
13 Clapboard 01235063 1
14 Condenser Assy 01163693 1
15 Inhalation Tube 03753450 1
16 Discharge Tube Sub-assy 03833306 1
17 Rear Grill 01473070 1
18 Valve Support Sub-Assy 01715020P 1
19 Cut-off Valve 07135058 1
20 Cut off Valve 07130239 1
21 Compressor and Fittings 00103903 1
22 Chassis Sub-assy 02803172P 1
23 Front Side Plate 01305086P 1
24 Left Handle 26235401 2
25 Cabinet 01435004P 1
26 Front Grill 22415003 1
27 Big Handle 2623500101 1
Above data is subject to change without notice.
