Gree GWH(09)MA-K3DNA3B - Page 10

8
Schematic Diagram
For 18K Unit
JUMP
CAP
EVAPORATOR
PE
TUBE
ROOM
N
DISP2
DISP1
AC-L
3BK
TEM.SENSOR
TEM.SENSOR
BK
AP1
ROOM
RT1
0
AP2
2BN
4YEGN
1BU
Outdoor Unit
BN
2
YEGN
3
BU
XT
N(1)
TUBE
0
RT2
COM-OUT
SWING-UD
PGFPG
FAN MOTOR
RECEIVER AND
DISPLAY BOARD
HEALTH-NHEALTH-L
COOL PLASMA
GENERATOR
BURD
SWING
MOTOR
M2
M1
(optional)
These circuit diagrams are subject to change without notice, please refer to the one supplied with the unit.
