GWH24AGD-K6DNA1A/O
No.ameN
1
Compressor three phase input
interface
2
Interface of system high pressure
protection
3
Compressor overload protection
5
Interface of electronic expansion
valve
interface
4Interface of temperature sensor
6
Interface of system low pressure
protection
7Interface of fan
84-way valve interface
10
11
92-way valve interface
12 Communication interface
14
13 Interface of live wire
Interface of earthing wire
15 Interface of netural wire
● Top view
● Bottom view
1234 65789
Interface of electric heating for
compressor
Interface of electric heating for
chassis
10
11
12
13
14
15
