Installation and Maintenance
Service Manual
NO. Description
1 Front Panel
2 Guide Louver (upper)
3 Guide Louver (lower)
4 Screw Cover
5 Front Case
6 Filter Sub-Assy
7 Helicoid Tongue
8 Air Louver
9 Left Axile Bush
10 Rear Case assy
11 Ring of Bearing
12 O-Gasket sub-assy of Bearing
13 Evaporator Support
14 Wall Mounting Frame
15 Evaporator Assy
16 Cross Flow Fan
17 Motor Press Plate
18 Fan Motor
19 Connecting pipe clamp
20 Drainage Hose
21 Stepping Motor
22 Stepping Motor
23 Crank
24 Main Board
25 Electric Box Assy
26 Terminal Board
27 Electric Box Cover
28 Display Board
29 Power Cord
30 Connecting Cable
31 Connecting Cable
32 Remote Controller
Some models may not contain some parts,
please refer to the actual product.
