1.
5.
upper hook
3.
indoor unit
band
2.
indoor
wall pipe
3.
4.
The power cord and control wire can't be crossed or
winding.
The drain hose should be bound at the bottom.
lower hook of
wall-mounting frame
4.
outdoor
Step 9:
Hang the indoor unit
sealing gum
2.
gas
pipe
liquid pipe
3.
4.
drain hose
5.
1.
indoor and
outdoor power cord
10
Step 8:
Bind up pipe
The wiring board is for reference only, please refer
to the actual one.
Do not bend the drain hose too excessively in order
to prevent blocking.
connection pipe
drain hose
band
indoor power cord
drain hose with the band.
Put the bound pipes in the wall pipe and then
NOTICE
NOTICE
NOTICE
Bind them evenly.
Bind up the connection pipe, power cord and
The liquid pipe and gas pipe should be bo-
und separately a t the end.
make them pass through the wall hole.
Hang the indoor unit on the wall-mounting
frame.
Stuff the gap between pipes and wall hole
with sealing gum.
Fix the wall pipe.
Check if the indoor unit is installed firmly and
closed to the wall.
Outdoor unit connection
N(1)
blue
2
black
3
brown
yellow-
green
Remove the wire clip; connect the power conn-
ection wire to the wiring terminal according to
the color; tighten the screw and then fix the po-
wer connection wire with wire clip.
Put wiring cover back and then tighten the screw.
Close the panel.
Reserve a certain length of drain hose and
power cord for installation when binding th-
em. When binding to a certain degree, sep-
arate the indoor power and then separate
the drain hose.
To Next Page
