8
Technical Information
Service Manual
Model GWHD(24)NK3MO(LCLH) GWHD(24)NK3MO
Product Code CB228W06600 CB228W06601
Power
supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling capacity(max~min) W 7100(2286~8499) 7100(2286~8499)
Heating capacity(max~min) W 8500(3664~8792) 8500(3664~8792)
Cooling Power Input(max~min) W 2180 2180
Heating Power Input(max~min) W 2280 2280
Cooling Current Input A 9.67 9.67
Heating Current Input A 10.12 10.12
Rated Power Input W 2870 2870
Rated Current A 12.73 12.73
SEER W/W 6.1 6.1
SCOP W/W 4.0 4.0
Outdoor
Unit
Compressor Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXAS-D23zX090B QXAS-D23zX090B
Compressor Refrigerant Oil Type RB68EP RB68EP
Compressor Type Inverter Rotary Inverter Rotary
L.R.A A 25 25
Compressor Rated Load Amp (RLA) A 11.5 11.5
Compressor Power Input W 2550 2550
Compressor Thermal Protector
"1NT11L-6233KSD115
O
C
HPC115/95U1"
"1NT11L-6233KSD115
O
C
HPC115/95U1"
Throttling Method Electron expansion valve Electron expansion valve
Cooling Operation Ambient Temperature Range
O
C -15~43 18~43
Heating Operation Ambient Temperature Range
O
C -20~24 -15~24
Condenser Material Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7 Φ7
Rows-Fin Gap(mm) mm 2-1.4 2-1.4
Coil length (l) X height (H) X coil width (L) mm 982.2X38.1X748 982.2X38.1X748
Fan Motor Speed (rpm) (H/M/L) rpm 800 800
Output of Fan Motor W 90 90
Fan Motor RLA A / /
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 4000 4000
Fan Type-Piece Axial-ow Axial-ow
Fan Diameter mm Φ520-120 Φ520-120
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5 2.5
Dimension (WXHXD) mm 1001X790X427 1001X790X427
Dimension of Package (LXWXH) mm 1080X485X840 1080X485X840
Dimension of Package(LXWXH) mm 1083X488X855 1083X488X855
Net Weight kg 68 68
Gross Weight kg 73 73
efrigerant Charge R410A R410A
Refrigerant Charge kg 2.2 2.2
