Wired Controller XK55
11
Button instruction
Number Name Definition
1
Receiving
window of
remote control
signal
It’s used for receiving the signal of remote controller
2
ON/OFF
indicator
Red color indicates the unit is off and white color indicates the
unit is on
3 Temp button It’s used for adjusting operating temperature
4 Mode button It’s used for switching operating mode
5 ON/OFF button It’s used for turning on or turning off the unit
6
Slight touch
button
Short press this button to switch on/off status
Long press this button for 5s to resume touch screen and LCD
7 Cooling button It’s used for selecting cooling mode
8 Heating mode It’s used for selecting heating mode
9 Fan button It’s used for switching fan speed
10 Function button It’s used for entering into next page
11 Status column It’ used for displaying time and starting up functions
12
Temperature
display
It’s used for displaying temperature
13
Fan speed
display
It’s used for display set fan speed
