120
Installation and Maintenance
Service Manual
NO. Description
1
Front Panel Assy
2 Display Board
3
Front Case Assy
4
Guide Louver
5 Air Louver
6 Swing Lever
7 Helicoid Tongue
8
Rear Case
9 Drainage Hose
10 Ring of Bearing
11 O-Gasket sub-assy of Bearing
12 Evaporator Support
13
Evaporator Assy
14 Wall Mounting Frame
15
Cross Flow Fan
16 Motor Press Plate
17 Fan Motor
18 Connecting pipe clamp
19 Rubber Plug (Water Tray)
20 Stepping Motor
21 Crank
22
Stepping Motor
23
Air Louver
24 Electric Box Assy
25 Air Louver
26 Axile Bush
27 Terminal Board
28 Jumper
29 Main Board
30 Shield Cover of Electric Box Cover
31
Electric Box Cover Sub-Assy
32 Electric Box Cover
33 Power Cord
34
Connecting Cable
35
Connecting Cable
36 Remote Controller
37 Cold Plasma Generator
38 Detecting plate(WIFI)
Some models may not contain some parts, please refer to the actual product.
