162
Installation and Maintenance
Service Manual
top cover
Step Procedure
4. Remove top cover
Remove connection screws connecting the top panel
with the front panel and the right side plate, and then
remove the top panel.
5. Remove grille
Remove connection screws between the front grille and
the front panel. Then remove the grille.
6. Remove front panel
Remove connection screws connecting the front panel
with the chassis and the motor support and then
remove the front panel.
grille
front panel
To Next Page
