28
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWH24ALD-K6DNA1B/O
Outdoor Unit Product Code CB513W02200
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model FTz-SM151AXBD
Compressor Oil FW68DA
Compressor Type Rotary
Compressor LRA. A /
Compressor RLA A 6.06
Compressor Power Input W 1330
Compressor Overload Protector /
Throttling Method Capillary
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature Range ºC -15~43
Heating Operation Ambient Temperature Range ºC -15~24
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94
Condenser Rows-n Gap mm 2-1.4
Condenser Coil Length (LXDXW) mm 848X38.1X528
Fan Motor Speed rpm 900
Fan Motor Power Output W 40
Fan Motor RLA A 0.70
Fan Motor Capacitor μF /
Heater Power Input W /
Outdoor Unit Air Flow Volume m
3
/h 2800
Fan Type Axial-ow
Fan Diameter mm Φ445
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 57/-/-
Sound Power Level (H/M/L) dB (A) 65/-/-
Dimension(WXHXD) mm 873X555X376
Dimension of Carton Box (LXWXH) mm 948X428X591
Dimension of Package(LXWXH) mm 951X431X620
Net Weight kg 36.5
Gross Weight kg 39.5
Refrigerant R32
Refrigerant Charge kg 1.23
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 1/2
Max Distance Height m 10
Max Distance Length m 25
Note: The connection pipe applies metric diameter.
