Technical Information
Service Manual
Model
1.GWH09PB-K3NNA6E 2.GWH09PB-K3NNA5E
3.GWH09PB-K3NNA2E 4.GWH09PB-K3NNA9E
5.GWH09PB-K3NNA3E
Product Code
1.CA430000700 CA430000701 2.CA417001700 CA417001701
3.CA415001700 CA415001701 4.CA429000800 CA429000801
5.CA416001700
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity W 2638
Heating Capacity W 2820
Cooling Power Input W 822
Heating Power Input W 781
Cooling Power Current A 4.45
Heating Power Current A 4.32
Rated Input W 1200
Rated Current A 6.43
Air Flow Volume(SH/H/M/L/SL) m
3
/h 450/400/320/250/-
Dehumidifying Volume L/h 1.2
EER W/W 3.21
COP W/W 3.61
SEER W/W /
HSPF W/W /
Application Area m
2
12-18
Indoor Unit
Model of Indoor Unit
1.GWH09PB-K3NNA6E/I 2.GWH09PB-K3NNA5E/I
3.GWH09PB-K3NNA2E/I 4.GWH09PB-K3NNA9E/I
5.GWH09PB-K3NNA3E/I
Fan Type Cross-ow
Diameter Length(DXL) mm Φ85X596
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1350/1250/1100/950/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1350/1250/1100/1000/-
Output of Fan Motor W 10
Fan Motor RLA A 0.15
Fan Motor Capacitor μF 1
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.5
Coil Length (LXDXW) mm 589X25.4X266.7
Swing Motor Model MP24AA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 38/35/31/28/-
Sound Power Level (SH/H/M/L/SL) dB (A) 48/45/41/38/-
Dimension (WXHXD) mm 790X265X179
Dimension of Carton Box (LXWXH) mm 870X255X350
Dimension of Package (LXWXH) mm 873X258X365
Net Weight kg 8
Gross Weight kg 10
