Technical Information
Service Manual
Model
1.GWH09PA-K3NNA7F 2.GWH09PA-K3NNA2F
3.GWH09PA-K3NNA1F 4.GWH09PA-K3NNA5F
Product Code
1.CA428000700 CA428000701 2.CA415003100
3.CA414002301 CA414002300 4.CA417002000
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity W 2638
Heating Capacity W 2814
Cooling Power Input W 939
Heating Power Input W 853
Cooling Power Current A 3.64
Heating Power Current A 3.46
Rated Input W 1350
Rated Current A 4.97
Air Flow Volume(SH/H/M/L/SL) m
3
/h 450/400/320/250/-
Dehumidifying Volume L/h 0.8
EER W/W 2.81
COP W/W 3.39
SEER W/W /
HSPF W/W /
Application Area m
2
12-18
Indoor Unit
Model of Indoor Unit
1.GWH09PA-K3NNA7F/I 2.GWH09PA-K3NNA2F/I
3.GWH09PA-K3NNA1F/I 4.GWH09PA-K3NNA5F/I
Fan Type Cross-ow
Diameter Length(DXL) mm Φ85X596
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1390/1280/1180/1080/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1350/1250/1140/1040/-
Output of Fan Motor W 10
Fan Motor RLA A 0.15
Fan Motor Capacitor μF 1
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.5
Coil Length (LXDXW) mm 589X25.4X266.7
Swing Motor Model MP24AA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 37/34/31/29/-
Sound Power Level (SH/H/M/L/SL) dB (A) 47/44/41/39/-
Dimension (WXHXD) mm 733X254X184
Dimension of Carton Box (LXWXH) mm 790X255X328
Dimension of Package (LXWXH) mm 793X258X343
Net Weight kg 8
Gross Weight kg 9.5
