Installation and Maintenance
Service Manual
NO.
Description
QtyGWH12NC-K3NNE4E/O GWH12NC-K3NNC7F/O
Product Code CA403W01600 CA195W06400
1 Front Grill 22413008 22413008 1
2 Front Panel 01533034P 01533034P 1
3 Chassis Sub-assy 0280325701P 02803253P 1
4 Drainage Connecter 06123401 06123401 1
5 Compressor and Fittings 00103937 00103937 1
6 Magnet Coil 4300040047 4300040047 1
7 4-way Valve Assy 03073310 03073140 1
8 4-way Valve 430004022 430004022 1
9 Strainer A 07210022 07210022 1
10 Capillary Sub-Assy 03163582 03163292 1
11 Valve 07100003 07100003 1
12 Valve 07100006 07100005 1
13 Big Handle 2623343106 2623343106 1
14 Valve Support 01703089P 01703089P 1
15 Right Side Plate Sub-Assy 01303172 01303172 1
16 Electric Box Assy 10000202153 10000201908 1
17 Terminal Board 42010265 42010265 1
18 Terminal Board 42011147 42011147 1
19 Capacitor CBB65 3300008102 3300008102 1
20 Capacitor CBB61 3301074710 3301074710 1
21 Rear Grill / / /
22 Condenser Assy 01103000293 01163910 1
23 Top Cover Sub-Assy 01253087 0125308701 1
24 Clapboard Sub-Assy 01233066 01233066 1
25 Motor Support 01703104 01703103 1
26 Fan Motor 150130676 150130676 1
27 Small Handle 26233100 26233100 1
28 Axial Flow Fan 10333427 10333427 1
Above data is subject to change without notice.
