Green Cell Wallbox - Installation Guide Mode C

Installation Guide
REFERENCE PAPER
of installing screw hole size
Hammer the
30mm PLASTIC BOLTS
into the holes
Take down the
REFERENCE PAPER
from the wall later
Embed STATION into
PLATE on the wall
This is the final completion pic,
you can put the HOOK
and HOLDER
anywhere you need
The cable can
be hung on the
HOOK and HOLDER
Fix the PLATE
with 30mm SCREWS
on the wall
Drill the holes
according to the
REFERENCE PAPER
Wall
Tear off the protector
