PRODUCT DESCRIPTION
CONDITIONS OF USE
This product is designed to extract clear water from deep wells or boreholes only. Any other use other than the
described above may cause dangerous situations and exempts the manufacturer from all liability.
DETAILED DESCRIPTION OF THE PRODUCT
TECHNICAL FEATURES
BAS125C
Power 1250W - 1,7cv
Voltage 240V / 50Hz
Motor Single phase
Output diameter 1,25” (3,175cm)
Maximum ow 5,5m3/h
Maximum pumping height 101m
Maximum water temperature 35ºC
Maximum depth 30m
NOTE: GREENCUT reserves the right to modify the technical characteristics without prior notice.
NOTE: The products detailed in this manual may vary in appearance, inclusions, description and
packaging as shown or described here.
1. Pump inlet
2. Pump body
3. Pump outlet
4. Handle / lifting point
5. Electrical connection cable
6. Control box (where applicable)
