Ceiling Exhaust Fans8
11. For grille with a module, refer to the following
installation method.
a. Insert the grille mounting spring on the wiring
side into the slot.
b. Insert the USB connector into the USB
receptacle (see page 4 for appropriate USB port
configuration) and insert other mounting spring
into the slot as shown and mount grille to fan
body. Avoid pinching module wires. (Fig. 12)
Fig. 12
To Next Page
