Climber 9.22/ Translation of the original instructions
The differential lock has to be activated when the pedal is half way of its travel (fig. 8). To adjust the activation point of the
differential lock use the screw (fig. 9).
MAINTENACE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER
20
HOURS
EVERY 40
HOURS
EVERY 50
HOURS
EVERY
100
HOURS
EVERY 200
HOURS
Engine oil
check the level ●
change ● ●
Air filter
check ●
replace ٭
Spark plug
check/adjust ●
replace ●
Hydraulic
engine oil
check level ● ●
replace ●
Check that the engine intake grid is
clean
●
Check that engine cooling fins and
cylinders are clean
●
Gearbox oil
check the level
● ●
replace
٭
Check that blades are well-sharpened
and well-fixed
●
Lubricate with grease
●
● recommended procedure
٭ procedure to be carried out if necessary
LUBRICATION POINTS WITH MACHINE GREASE
CUTTING DECK LUBRICATION WITH ADDITIONAL GREASER PLACED ON IT (fig. 26)
