Grillstream GCH45MG - Page 14

GCH45MG
Page 14
4 x B
Insert and part tighten bolts (B) into Cabinet Side Panels (7 & 8). Slot Cabinet Rear Panel (9)
into place and secure to Cabinet Base Panel (6) with Bolts (B). Now fully tighten bolts into
Cabinet Side Panels (7 & 8).
STEP 3
Part B
QTY 4
M6x12 Bolt
7
8
9
x 4 x 12
x 44 x 12
x 2
x 44
