Grillstream GCH45MG - Page 20

GCH45MG
Page 20
2 x D
2 x B
Further secure Side Shelf (12) in place from inside the cooking frame using Bolts (B) and
Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the
cooking frame.
STEP 9
Part B
QTY 2
M6x12 Bolt
Part D
QTY 2
x 4 x 12
x 44 x 12
x 2
x 44
Washer
x 4 x 12
x 44 x 12
x 2
x 44
