Grillstream GCH45MG - Page 22

GCH45MG
Page 22
2 x D
2 x B
Further secure Side Burner Shelf (19) in place from inside the cooking frame using Bolts (B)
and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the
cooking frame.
STEP 11
Part B
QTY 2
M6x12 Bolt
Part D
QTY 2
x 4 x 12
x 44 x 12
x 2
x 44
Washer
x 4 x 12
x 44 x 12
x 2
x 44
