Model G0750G (Mfg. Since 11/12)

REF PART # DESCRIPTION REF PART # DESCRIPTION

701 P0750G0701 TOOL POST HANDLE M12-1.75 X 8 720 P0750G0720 GIB SCREW

702 P0750G0702 TOOL POST HANDLE HUB 721 P0750G0721 COMPOUND LEADSCREW NUT

703 P0750G0703 TOOL POST BUSHING 722 PN01M HEX NUT M6-1

704 P0750G0704 QUICK CHANGE TOOL POST BLOCK 723 PSS11M SET SCREW M6-1 X 16

705 P0750G0705 TOOL POST BOLT M16-1.5 X 35 724 P0750G0724 SWIVEL SLIDE

706 PLUBE002M BALL OILER 8MM TAP-IN 725 PW01M FLAT WASHER 8MM

707 P0750G0707 COMPOUND REST 726 PN18M ACORN NUT M8-1.25

708 P8101 THRUST BEARING 8101 727 P0750G0727 COMPOUND REST GIB

709 P0750G0709 BEARING HOUSING 728 PSS03M SET SCREW M6-1 X 8

710 PCAP06M CAP SCREW M6-1 X 25 729 P0750G0729 SLIDE NUT

711 P0750G0711 GRADUATED DIAL 730 P0750G0730 COMPRESSION SPRING

712 P0750G0712 COMPOUND REST HANDWHEEL 731 P0750G0731 ALIGNMENT PIN

713 P0750G0713 INNER HUB 732 PSS126M SET SCREW M10-1.5 X 14 PILOT

714 PSS26M SET SCREW M5-.8 X 6 733 PFN08M FLANGE NUT M16-1.5

715 P0750G0715 COMPOUND REST HANDLE 734 P0750G0734 SHOULDER BOLT M8-1.25 X 8

716 P0750G0716 COMPRESSION SPRING 735 PSS125M SET SCREW M10-1 X 45

717 PSTB006M STEEL BALL 4MM 736 P0750G0736 KNURLED THUMB NUT M10-1

718 PK05M KEY 4 X 4 X 10 737 P0750G0737 WAVY WASHER 10MM

719 P0750G0719 COMPOUND SLIDE LEADSCREW 738 PN14M HEX NUT M10-1

Compound Rest & Tool Post Parts List
