Model G0750G (Mfg. Since 11/12)
-105-
Lathe Bed & Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
901 P4003G801 COGGED V-BELT V13X795 934 P07091134 END PLUG
902 PSS05M SET SCREW M5-.8 X 10 935 PLUBE001M BALL OILER 6MM TAP-IN
903 PK107M KEY 8 X 8 X 20 936 PCAP35M CAP SCREW M8-1.25 X 60
904 PW04M FLAT WASHER 10MM 937 P07091137 TAPER PIN 5 X 60
905 PB32M HEX BOLT M10-1.5 X 25 938 P07091138 LOCK COLLAR
906 P4003G0806 MOTOR 2HP 220V 1-PH 939 PSS03M SET SCREW M6-1 X 8
906-1 P0750G0906-1 MOTOR FAN COVER 940 P07091140 LOCKING BEARING COVER
906-2 P0750G0906-2 MOTOR FAN 941 PSS16M SET SCREW M8-1.25 X 10
906-3 P0750G0906-3 MOTOR JUNCTION BOX 942 P07091142 FEED ROD
906-4 P0750G0906-4 MOTOR TERMINAL BLOCK 943 P07091143 INDEX LUG PIN
906-5 P0750G0906-5 S CAPACITOR COVER 944 PSS124M SET SCREW M8-1.25 X 16 PILOT POINT
906-6 P0750G0906-6 S CAPACITOR 150M 250V 1-5/8 X 3-1/8 945 P07091145 LOCK COLLAR
906-7 P0750G0906-7 R CAPACITOR COVER 946 P07091146 SPINDLE ON/OFF LEVER
906-8 P0750G0906-8 R CAPACITOR 20M 450V 1-1/2 X 2-3/4 947 P07091147 BALL KNOB M10-1.5 ROUND
906-9 P0750G0906-9 CONTACT PLATE 948 PCAP01M CAP SCREW M6-1 X 16
906-10 P0750G0906-10 CENTRIFUGAL SWITCH 949 P07091149 HOUSING
906-11 P0750G0906-11 MOTOR FRONT BALL BEARING 950 P07091150 COMPRESSION SPRING 1 X 6 X 20
906-12 P0750G0906-12 MOTOR REAR BALL BEARING 951 P07091151 THRUST WASHER
907 P4003G0807 SPLASH GUARD 952 PK68M KEY 4 X 4 X 40
908 P4003G0808 MOTOR PULLEY 953 P07091187 FLANGED SLEEVE
909 P4003G0809 MOTOR BRACKET 954 P07091188 CONTROL ROD
910 PB01M HEX BOLT M10-2.5 X 30 955 PSS123M SET SCREW M8-1.25 X 10 CONE POINT
911 PRP49M ROLL PIN 5 X 25 956 PRP28M ROLL PIN 5 X 40
912 PW04M FLAT WASHER 10MM 957 P07091191 CLUTCH ASSEMBLY
913 PCAP06M CAP SCREW M6-1 X 25 958 P07091192 COMPRESSION SPRING
914 P4003G0814 GAP RACK 959 PSTB003M STEEL BALL 6MM
915 P4003G0815 GAP PIECE 960 P07091194 SHEAR PIN
916 PCAP70M CAP SCREW M10-1.5 X 45 961 P0750G0961 STUD-UDE M10-1.5 X 145, 35, 25
917 P4003G0817 THREADED TAPER PIN 8 X 45 962 PN02M HEX NUT M10-1.5
918 PS68M PHLP HD SCR M6-1 X 10 963 P07091121 KNURLED KNOB M10-1.5
919 PW03M FLAT WASHER 6MM 964 P0750G0964 RIGHT STAND BASE
920 P4003G0820 LATHE BED 964-1 P0750G0964-1 RIGHT STAND DOOR
921 P4003G0821 CHIP PAN 964-2 P0750G0964-2 DOOR LATCH
922 P4003G0822 RACK 964A P0750G0964A RIGHT STAND ASSY
923 PRIV001M RIVET 2 X 5MM STEEL FLUTED 965 P4003G0830 RIGHT PANEL BRACKET
924 P4003G0824 INFORMATION PLATE 966 PS05M PHLP HD SCR M5-.8 x 8
925 P0750G0925 LONGITUDINAL LEADSCREW 967 PW02M FLAT WASHER 5MM
926 P07091126 SLEEVE 968 PN06M HEX NUT M5-.8
927 P8102 THRUST BEARING 8102 969 P4003G0833 FRONT PANEL
928 P8104 THRUST BEARING 8104 970 P4003G0834 LEFT PANEL BRACKET
929 P07091129 HOUSING 971 P4003G0836 LEFT STAND BASE
930 P07091130 BEARING COVER 971-1 P4003G0836-1 LEFT STAND DOOR
931 P07091131 SHOULDER FLANGE SCREW 971A P4003G0836A LEFT STAND ASSY
932 PSS122M SET SCREW M6-1 X 20 CONE POINT 972 PW10M FLAT WASHER 14MM
933 P07091133 END PLUG 973 PB129M HEX BOLT M14-2 X 45
To Next Page
