G1033 20" Planer -27-
Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G1033 20" PLANER
MACHINE DATA
SHEET
Design Type .................................................................................................... Floor Model
Overall Dimensions:
Table Size ....................................................................................................25
3
⁄4" x 20"
Height........................................................................................................................41"
Overall Depth ............................................................................................................39"
Overall Width ............................................................................................................58"
Shipping Weight ................................................................................................770 lbs.
Base Dimensions ..................................................................27
1
⁄
2" L x 23" W x 13
3
⁄
4" H
Crate Size ..................................................................................29" L x 40" W x 44" H
Footprint ........................................................................................................22" x 28"
Capacities:
Maximum Depth of Cut ..............................................................................................
1
⁄8"
Maximum Width of Cut..............................................................................................20"
Maximum Cutting Height..........................................................................................8
5
⁄8"
Minimum Stock Thickness ........................................................................................
1
⁄4"
Minimum Stock Length ..............................................................................................7"
Cutterhead Speed ........................................................................................4833 RPM
Cuts per Minute ..................................................................................................19,332
Feed Rates ......................................................................................16 FPM & 20 FPM
Cuts Per Inch ..................................................................................................104 & 83
Construction:
Table ..................................................................................Precision-Ground Cast Iron
Power Feed Rollers ....................................................................Metal/ Spiral Serrated
Stand ........................................................................................................Formed Steel
Cutterhead ........One Piece Machined Shaft; 4 Knife Slots w/ Shielded Ball Bearings
Motor:
Type ............................................................................TEFC Capacitor-Start Induction
Horsepower ............................................................................................................3HP
Phase ⁄ Voltage ................................................................Single Phase / 220V / 240V
Amps ..........................................................................................................................18
Cycle ⁄ RPM ..................................................................................60 Hertz ⁄ 3450 RPM
Switch ........................................................Magnetic With Thermal Overload Protector
Power Transfer ....................................................................................Triple Belt Drive
Bearings..........................................................Shielded & Permanently Lubricated Ball
Features:
Roller Extension Tables ..................................................................1 Adjustable Roller
Table Movement ............................................................................................
1
⁄4" to 8
1
⁄2"
Table Locks................................................................................................Two Positive
Dust Port ....................................................................................................................5"
Measurement Scale ..................................................................................Inch & Metric
Bed Rollers ................................................................................................2 Adjustable
Specifications, while deemed accurate, are not guaranteed.
REVISED 4/99
