Grizzly G1066R User Manual

Model G1066R/Z/G1079R (Mfd. Since 02/11)
-11-
Machine Data Sheet (G1066Z)
The information contained herein is deemed accurate as of 10/29/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G1066Z
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G1066Z 24" DRUM SANDER W/ VS
Product Dimensions:
Weight.............................................................................................................................................................. 389 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 50 x 37 x 44-1/2 in.
Footprint (Length x Width)..................................................................................................................... 34-1/2 x 24 in.
Shipping Dimensions:
Type............................................................................................................................. Cardboard Box on Metal Skids
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 489 lbs.
Length x Width x Height....................................................................................................................... 41 x 38 x 43 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating........................................................................................................................................ 27A
Minimum Circuit Size.............................................................................................................................................. 30A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 8 ft.
Power Cord Gauge......................................................................................................................................... 12 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type................................................................................................................................... L6-30
Switch Type............................................................................................ Control Panel w/Magnetic Switch Protection
Motors:
Main
Horsepower................................................................................................................................................ 5 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 25A
Speed................................................................................................................................................ 3450 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer ...................................................................................................................... Twin V-Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External
Feed
Horsepower............................................................................................................................................. 1/3 HP
Phase............................................................................................................................................ Single-Phase
Amps.............................................................................................................................................................. 2A
Speed.................................................................................................................................................... 60 RPM
Type..................................................................................................................................................... Universal
Power Transfer ............................................................................................................................... Chain Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type................................................................................................................ N/A
