Ground Hog HD99 - Page 7

Attach the towbar to the axle tow tabs as shown below.
TOWING AND TRANSPORTATION cont’d...
ATTACHING THE TOWBAR TO THE HD99 cont’d...
Lower the earth drill until towbar attachment stem rests in-between the towbar attach-
ment plates .
STEP 3
Towbar
Axle tow tabs
Insert the hitch pin all the way through the holes on the towbar stem and attachment
plates.
STEP 4
STEP 5
Hitch pin
Hitch pin retainer
Page 6
®
HD99
