Technical Speciļ¬cations
Frequency
Range 5 - 3300 MHz
Accuracy 1 kHz
Tuning Frequency or channel
Input
Impedance
50 Ohm
ASI IN/OUT
Spectrum Analyser
Span
100 KHz, 1, 5, 10, 20, 50, 100, 200, 500 MHz, 1.0,
2.0 and 3.3 GHz. Other (any value between 100
KHz and 3.3 GHz)
RBW
500 Hz, 1, 3, 5, 10, 30, 50, 100, 300, 500 KHz,
1, 3, 5 MHz
Marks Up to 4, with delta feature
Event trigger
Waterfall
Hold feature Maximum and minimum
Reference level Automatic and manual
Digital measurements ATSC3.0
Freq. Range 42-1800MHz
MPEG image
Modulation
QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, and
4096QAM
Power -90 - 20 dBm
MER Up to 40dB
LDPCBER 1.0E-2 - 1.0E-6
BCHBER 1.0E-2 - 1.0E-8
C/N Up to 40dB
Constellation
Echoes
Uncorrected packets
TILT
Attenuation
Digital measurements ATSC1.0
Freq. Range 42-1800MHz
MPEG image
Modulation 8VSB
Power -90 - 20 dBm
MER Up to 40dB
PreBER 1.0E-2 - 1.0E-8
PostBER 1.0E-2- 1.0E-9
Constellation
MER by carrier
Constellation
Uncorrected packets
TILT
Attenuation
Digital measurements QAM (Anex A/B/C)
Modulations 4QAM, 16QAM, 32QAM, 64QAM and 256QAM
Power -90 - 20 dBm
PreBER 1.0E-2 - 1.0E-8
PostBER 1.0E-2 - 1.0E-9
MER Up to 40dB
C/N Up to 52dB
Constellation
Uncorrected packets
TILT
Attenuation
Digital measurements DVB-S
Wideband
(only compatible HW)
250-2400 MHz
Power -90 - 20 dBm
CBER 1.0E-2 - 1.0E-6
VBER 1.0E-2 - 1.0E-8
MER Up to 20dB
C/N Up to 30dB
Constellation
Uncorrected packets
TILT
Attenuation
Digital measurements DVB-S2X (option 901626)
Wideband 250-2400 MHz
Modulations
QPSK, 8PSK
Power -90 - 20 dBm
Link Margin
Up to 10dB
MER
Up to 20dB
C/N
Up to 30dB
LDPCBER
1.0E-2 - 1.0E-6
BCHBER
1.0E-2 - 1.0E-8
Constellation
Uncorrected packets
TILT
Attenuation
Multi TS
PLS scrambling
Digital measurements DVB-S2
Wideband 250-2400 MHz
