Installation
at least 190cm
Using a spirit level measure a horizontal line at
least 190cm from the floor. Position the heater
in the required position so the centres of the
holes of the wall bracket are on the line. Mark
the hole positions.
Using a 8mm bit drill two holes in the marked
positions.
6
WARNING: Before drilling holes check the wall/ceiling is solid and that there are no
hidden water pipes or electric wires.
at least 40cm
at least 180cm
30
º
- 45
º
at least
40cm
at least
40cm
at least
40cm
The heater must be installed no less than 40cm (16”) from side walls and no less than 180cm
(6.0’) above the floor. Also consider proximity to a mains plug socket.
