Guerrilla Gravity The Smash - Page 7

Assembly - Chainline
RaceFace Cranks – 55mm Chainline
134mm Spindle
2.5mm BB spacer
Chainring
dished out
2.5mm BB spacer
Chainring
dished in
143mm “Plus” Spindle
Notes:
• Pedälhead frame shown for clarity, setup is the same for The Smash
• For Sram cranks, use a 0mm offset direct mount chainring and install per normal
