Operation &
Maintenance
Manual
A6ML0066 – Euroblast SF Instruction Manual
41 Dust collector
Air flow is controlled by the slide damper on the
exhaust outlet on the dust collector.
C400 Dust collector
Air flow is controlled by the slide damper on the
exhaust outlet on the dust collector.
C400, C600 and C800 Dust collector
Air flow is controlled by the blast gate on the inlet to
the dust collector.
A blast gate will be fitted to the C400 if a cyclone is
being used.
The dust collector must be started before and stopped after the cyclone unit (if fitted) in order to clear
the system of dust after the blasting operation.
The dust collector should be checked to see how much reusable media has been transferred and the
settings adjusted accordingly.
Never try to extract reusable media for reuse in the machine.
On a C800 it is essential that a plastic bin liner (Y1CA0047) is used. It provides a simple and
clean means of removing and disposing of the dust, but its use requires balancing the pressure either
side of the bag to prevent it being drawn up into the hopper. This is achieved by the use of the bin
balance pipe so that the same negative pressure is applied to the outside of the bag as the inside.
If a bin liner is not used then dust will be drawn up through the bin balance pipe into the clean side of
the dust collector.
