7.1.10.3 Replacing the filter cartridge on a C600
Press the filter cleaning push button and turn off the air supply
1. Turn anti-clockwise to unlock
2. Open door.
3. For filter removal turn lifter cam 90° to the right
4. The cam is now unlocked and the filter cartridge can be removed
5. Replace with new filter cartridge (Y1CA0049)
6. Turn lifter cam 90° to the left to lock cartridge
7. Close door and lock
2
4
5
6
8
3
7
