2.2 Cyclones
Cyclone & Dust collector combination
HE with
C400 D/C
75/16 with
41D/C
75/16 with
C400 or
C800 D/C
CY600/12
with C800
D/C
CY600/16
with C800
D/C
Inlet diameter (mm)
100
100
100
100
100
Outlet diameter (mm
150
100
150
150
150
Airflow (m³/min)
8.0
12.0
Height (mm)
1915
*
*
2776
3145
Base diameter (mm)
700 x 860
*
*
750
750
Body diameter (mm)
400
400
400
300
400
*Dependant on whether cyclone is free standing or cabinet mounted
2.3 Dust collectors
Dust collector model number
41
C400
C600
C800
Inlet diameter (mm)
100
150
150
150
Extraction outlet
Open exhaust
Maximum inlet static pressure
(mm Wg)
150
165
165
230
Maximum inlet static pressure
(Pa)
1470
1620
1620
2255
Measured airflow (with open
inlet/outlet) (m
3
/min)
10
11
11
33
Airflow adjustable?
Yes
Number of primary filters
4
1
1
2
Type of primary filter
B
A
A
A
Filtration area
1.8 m
2
17.5 ft
2
10 m
2
97 ft
2
10 m
2
97 ft
2
20 m
2
194 ft
2
Air flow rating
(with a filter velocity of 1.5
m/min)
162 m
3
/hr
95 CFM
900 m
3
/hr
530 CFM
900 m
3
/hr
530 CFM
1800 m
3
/hr
1059 CFM
Filter cleaning system
C
D
D
E
Air consumption (litres per
pulse)
N/A
7
7
7
Maximum compressed air
supply pressure
N/A
50 psi
3.5 bar
50 psi
3.5 bar
50 psi
3.5 bar
where:
A
Cartridge Filter - Polyester Element
B
Fabric filter - Polyester needlefelt - Scrim reinforced
C
Manual shaking system
D
Manual Pulse Air Cleaning System
E
Auto Pulse Air Cleaning System
