Guyson 6 - Page 66

Operation &
Maintenance
Manual
Issue:
10
A6ML0066 – Euroblast SF Instruction Manual
Date:
05/2019
Page: 66
Pos.
Item number
Description
1
P4AP0027
Filter 1/2” BSP Autodrain
2
P4AP0030
Regulator 1/8” BSP Pilot Reg
3
P4VL0033
Plunger Valve 3/2” 1/8” NPT
4
P4AP0028
Regulator 1/2” BSP P/Operated
5
P4SD0000
Press Gauge Panel 0-10 Bar
6
P4VL0059
Plunger 2/2 Valve 1/4” BSP
7
P4VL0072
Valve Trigger Gun (2006ga44)
8
E1AA0032
Mounting Bracket
9
P1TH0184
Hex.Skt. Button Screw M8 x 16
10
P1TH0228
Nutsert M8
11
P1TH0093
Hex.Skt.Cap Screw M5 x 10
12
D1MC0000
Manifold A3201 (3 Outlets)
13
P4MN0179
Locknut 1/2” BSP (Manifold)
14
P1WS0036
Washer Dowty 1/2"
15
D1MC0001
Manifold A15249
16
P4CG0001
Hosetail 1/4" BSP x 10mm Hose
17
P1HC0000
Hose Clip 10mm
18
Y1BB0422
Label, "Ps: 6.0 Bar"
19
Y1BB0056
Label "Fit Hand Valve ...."
20
P4TF0132
Hosetail Barb 1/8" - 1/8" NPT
21
P1TH0025
Hex. Set Screw M5 x 25
22
P1WS0012
Spring Washer M5
23
E1AA0031
Valve Locating Pin
24
P4SL0002
Silencer 1/8” NPT
25
P2GT0013
PVC Black End Cap
26
P4MN0151
Bush Red 1/4” x 1/8” BSP
27
P4MN0089
Nipple Barrel 1/2” BSP
28
P4MN0000
Elbow Fem. 1/8” BSP
29
P4MN0019
Elbow M/F 1/2” BSP
30
P4MN0155
Bush Red. 1/2” x 1/4” BSP
31
P1TH0030
Hex. Set Screw M6 x 12
32
P1WS0003
Plain Washer M6
33
P2GT0009
Grommet 5.6 x 8mm
34
P2GT0000
Grommet 10mm PVC Hose
35
R6TB0003
Hose 10mm x 16 OD Braided PVC
36
R6TB0046
Tube 1/8" Id Blue PU
37
P4VL0114
Ball Valve 1/2" BSP Venting
38
P1TH0213
Hex. Nut M5 Nyloc
39
P1WS0002
Plain Washer M5
40
P4MN0134
Plug Solid 1/4” BSP
