2. Data sheets
2.1 Blast cabinets
Euroblast cabinet model number
2
4
6
7
8
9
10
Overall dimensions
Height (mm)
1600
1655
1825
1825
1825
2265
2125
Width (mm)
680
815
1070
1500
1070
1220
1500
Depth (mm)
500
560
760
915
1070
1220
1500
Blast chamber dimensions
Height (mm)
500
715
880
880
880
1325
1145
Width (mm)
660
800
1050
1480
1050
1200
1480
Depth (mm)
480
540
740
900
1050
1200
1480
Turntable diameter (mm)
N/A
400
600
750
750
900
900
Evenly distributed
maximum load (kg)
Floor
200
400
350
650
500
500
750
Turntable
N/A
200
450
450
500
500
500
Average noise levels
at 1 Metre
with dust collector
{dB(A)}
<80
<80
<80
<80
<80
<80
<80
with dust collector
and cyclone {dB(A)}
<80
<80
<80
<80
<80
<80
<80
Floor height (mm)
960
810
845
845
845
805
845
Armhole height (mm)
1070
1040
1075
1075
1075
1045 +
1510
1075
Maximum air pressure
90 psi or 6 bar
Maximum air supply
77.4 m
3
/hr or 42 CFM
Cabinet lighting
Electric supply
LED link light
Fuse rating
Single phase, 230 V, 50 Hz
7 W
2 A
Operator protection required
Hand and lower arm by gloves or gauntlets (supplied)
