Characteristics Example
As can be seen in the following figure, a component can have
different effective parameter values dependent upon its operating
condition. The measured values most useful in actual applications
are obtained from precise measurement under the actual operating
conditions.
DUT
Characteristics Example
Measurement
Functions
Large C
Cs-Rs
Cs-D
Cs-Q
R-X
|Z|-∠θ
Small C
Cp-G
Cp-D
Cp-Q
G-B
Y-∠θ
