Installation Manual
H3C S3600 Series Ethernet Switches Chapter 3 Installation
3-9
Front panel
Figure 3-12 Install front mounting ears and guide rails
5) Fix the other end of front mounting ears to the front brackets of the cabinet with M6
screws and captive nuts and ensure that the front mounting ears and guide rails
have fixed the switch in the cabinet securely, as shown in
Figure 3-13.
Rear panel
Guide
rail
Figure 3-13 Effect diagram of front mounting ear and guide rail installation
