Logarithmic output mode
Figure 14 shows in graph form the operation of the logarithmic output mode.
Figure 14 Logarithmic output
1 Output current axis 4 50% value 7 Maximum output current
(20 mA)
2 Source value axis 5 Minimum output current
(0-4 mA)
3 High value 6 50% output current
