5
RUNNING YOUR CAR
5
TO TUNE THE STEERING TRIM
Gently pull the trigger to allow your car to run slowly. Meantime, tune the steering trim to allow the
front wheels to be aligned.
STEERING TRIM
7
TO TUNE THE STEERING DUAL RATE CONTROL DIAL
This dial adjusts the overall travel of the steering servo. Push the dial forward for maximum
steering. Pull the dial back to reduce the steering level.
- Set the Steering Dual Rate Control Dial to Minimum first. To set the desired steering level
increase it again whilst decelerating your vehicle.
Decrease
Increase
STEERING D/R
6
TO TUNE THE THROTTLE TRIM
Throttle trim is used to set your idle speed.
THROTTLE TRIM
8
STEERING/THROTTLE REVERSE
Steering Reverse: It allows you to electronically switch the
direction of steering servo travel. For example, if you move
the steering wheel to the right and the steering servo moves
to the left,flip the Steering Reverse Switch to make the steering
servo move to the left.
Throttle Reverse : It allows you to electronically switch the
direction that the motor operates in relation to the throttle trigger.
For example, if you pull the throttle trigger to accelerate forward,
but the model goes in reverse, flip the Throttle Reverse Switch
to make the model accelerate forward.
N: Normal
R: Reverse
N: Normal
R: Reverse
