Service Manual
Model No.:
7-2 .Wiring Connection Diagram
- 31 -
1
2
4
3
NO.N ame
1
2
3
4
Connection Wire(For Remote and Keyboard)
Connection Wire(For Speaker)
LVDS Wire
Connection Wire(Power For Mainboard)
