3 MECHANICAL DATA
3.1 Drawings / Dimensions
3.1.1 Cassette Indoor unit
3.1.2 outdoor unit
Swing louver
(Air flow direction can be adjusted by using
the SWING button on the remote controller)
Electrical Components Case
Air Inlet Grille
Air Filter (Inside of the Inlet Grille)
Air inlet
Air outlet
Compressor(inside of unit)
18 series
