Rev. Ref1010S025V0
which may interfere with the removal of the freezing air-duct .
(2) detach 4 screws in lower of the middle clapboard (fig ①);
(3) Disconnect the connector of the middle clapboard(fig ②);
(4) Remove the middle clapboard from the lower ; (fig ③);
(5) Detach the screw of the duct cover and remove it. (fig ④);
(6) Pull out the connectors and disconnect them (fig ⑤);
(7) Remove 4 small duct cover and detach 4 screws in the freezing air-duct onto the freezer
chamber (fig ⑥);
(8) Tilt the freezing air-duct forward from top to bottom and disconnect the connectors of the
freezing air duct ,then you can remove the air-duct (fig ⑦);
(9) Take out the freezing air-duct and the fin evaporator is just behind it (fig ⑧).
When reinstalling, please connect the connector first and then mount and fix the freezing
air-duct.
