SERVICE MANUAL
Model: BD-103GAA
7
Issue 2009-12-17
Rev.
Ref0912S015V0
Cabinet
white
Top
white
Door glass
-
Door frame
white
Fascia panel / Handle (w/b/g/s)
white/white
Inside door/-drawers (W=white T=transparent)
-/-
5. Equipment & accessories
Product classification (Super eco/Eco/Standard)
Eco
Lid (Number/Handle/Lock)
1/●/-
Type of lid (Hinge/Counter balanced/Sliding)
Hinge
Inside walls (Stainless steel/Aluminium/Synthethic
mat.)
Anodized Aluminum
Insulation Lid thikness
7.85
Walls thikness
6.5
Baskets number
1 (metal)
Defrost drain
●
Interior light
-(Optional)
Calendar
-
Adjustable thermostat
●
Fast freeze lamp (yellow)
●
On light (green)
●
Breakdown light (red)
●
Fast freeze switch
●
Freezer temperature warning indicator (LED / by sound)
-
Thermometer (Outside / In partition)
-
Maximum loading level marking
-
Adjustable feet (front / rear)
-(unable adjustable
feet)
Mobility wheels (front / rear)
-(Optional)
Flush back skin evaporator
-
6. Product net dimensions
Unit dimensions (H / W / D) 84.5/57/55
Height with open lid
134.5
Net weight
31
7. Packing dimensions & loadability
Packing dimensions (H / W / D) 89/62.5/58.5
Gross weight
34
20 ' container load
75
40 ' container load
151
40 ' High cube container load
227
8. Service
User instruction (languages)
GB,DE,FR,IT,SP,PT,NL
