ii. Deslice la chimenea para ajustar la altura de la chimenea. Cuando se
alcance la altura requerida, entonces cuelgue el agujero de fijación a
los tornillos de fijación como se muestra en las fig. de abajo.
8.
i. Perfore 2 agujeros de 8 mm para acomodar la placa II. Atornille y
apriete la placa II en la pared con los 2 tornillos suministrados.
ii. Monte la chimenea en la unidad y fíjela con 2 tornillos.
Chimenea interior
Chimenea exterior
Placa II
Taco
Tornillo
4
mm x 8 mm
Tornillo
4
mm x 30 mm
66
