Haier HR-710FD - Page 35

A
B
M
N
O
θ
C
D
E1
E2
E3
F
G
H1
H2
H3
H4
I1
I2
I3
K
L
J
E1. Refrigerator door switch 1
E2. Refrigerator door switchl 2
E3. Freezer door switch
F. Control panel
G. Cooling fan motor H1. Defrost sensor
H2. Freezer sensor
H3. Refrigerator sensor
H4. Environment sensor
I1. Freezer lamp
J. Refrigerator heater
K. Defrost heater
I2. Refrigerator lamp 1 I3. Refrigerator lamp 2
L. Fuse
M. Overload protector N. Compressor
O. PTC
A.Power plug
B.Freezer fan motor
C.Refrigerator damper
D.Door display panel
220-240V~
50Hz
HB21T / HB21TNN / HTD647SS / HTD647SSI / HRF-649T
HRB-702MP/S / HRB-702F/SS
E1. Refrigerator door switch 1
E2. Refrigerator door switchl 2
E3. Freezer door switch
F. Control panel
G. Cooling fan motor H1. Defrost sensor
H2. Freezer sensor
H3. Refrigerator sensor
H4. Environment sensor
I1. Freezer lamp
J. Refrigerator heater
K. Defrost heater
I2. Refrigerator lamp 1I3. Refrigerator lamp 2
L. Fuse
M. Inverter N. Compressor
A.Power plug
B.Freezer fan motor
C.Refrigerator damper
D.Door display panel
A
B
M
N
C
D
E1
E2
E3
F
G
H1
H2
H3
H4
I1
I2
I3
K
L
J
220-240V~
50Hz
HB21TB / HB21TNNB / HR-710FD
