Please close the panels
before start the removal
procedure of front grille.
Slide the front panel from
one side to another to
release each axis.
Open the front panel
until it is on the
horizontal position,
and then release the
pivots on both sides of
the unit to remove the
front panel.
Removal Procedure
67 Domestic Air Conditioner
