Faulty Compressor Unit
- Compressor
- Refrigerator cycle
The refrigerator remains warm
even though the compressor
has been operational for more
than 30 minutes.
Does defrost timer operate?
Defrost
Check for continuity
between terminals
YES YES
3. No Defrosting
Does the compressor stop
running when the shaft of
the defrost timer is turned
clockwise until its first click
is heard.
hermal Fuse
Check for the continuity
between WHITE lead wires. At
room temperature, it should
be closed.
Bimetal
hermostat
Check for the continuity
between BROWN and WHITE
lead wires. At room
temperature, it should be
closed.
D
Check for the continuity
between RED and WHITE lead
wires
The Freezer And Refrigerator Rooms Are Not Sufficiently Cold
Check Point
Indication
Cause Of Trouble
Instruction (Diagnosis)
- Does the processor operate?
- Is refrigerator installation distant from direct
heat?
- Is the condenser radiating efficiently?
- Is there any hot foodstuff in refrigerator?
- Excessive foodstuff stored or interference with
cold air circulation
- Is temperature control knob in suitable position?
- Is the gasket sealing in
good condition?
To Next Page
