7.1.1 The operation frequency of outdoor unit and its control
7.1.1.1 The operation frequency control of compresso r
The operation frequency scope of compressor
Mode Minimun operation frequency Maximun operation frequency
zH811zH03gnitaeH
zH08zH52noitaregirfeR
7.1.1.2 The starting of compressor
When the compressor is started for the first time, it must be kept under the conditions of
30Hz,40Hz,58Hz for one minute (the overheating protection of the outdoor unit air-blowing temperature,
immediately decrease the frequency when the compressor is overflowing and releasing the
pressure)
then it can be operated towards the target frequency. When the machine runs normally,
there’s no such process. After starting the compressor for operation, the compressor should run
according to the calculated frequency, and every determined frequency for protection should be
prior to the calculated frequency.
7.1.1.3 The speeds of increasing or decreasing the frequency of the compressor
The speed of increasing or decreasing the frequency rapidly 1 -----------1HZ/second
The speed of increasing or decreasing the frequency slowly 2 -----------1HZ/10seconds
7.1.1.4 The calculation of the compressor’s frequency
1 The minimum/maximum frequency limitation
A
While refrigerating: is the maximum operation frequency of the
compressor;
IN is the minimum operation frequency of the compressor.
B
While heating: is the maximum operation frequency of the compressor;
IN is the minimum operation frequency of the compressor.
1
The frequency limitation which is affected by the environment temperature.
Heating mode:
7.1 The control system of outdoor unit
.
7.Functions and Control
Functions and control
Domestic air conditioner
16
Serial
No.
Temperature scope Frequency limitation
1 Wh_c<-12 Max_hz1 118HZ
2 Wh_c<-8 Max_hz2 118HZ
3 Wh_c<-2 Max_hz3 118HZ
ZH8114zh_xaM5<c_hW4
5 Wh_c<10 Max_hz5 118HZ
6 Wh_c<16 Max_hz6 118HZ
7
Wh_c<
20
Max_hz7 112HZ
8
Wh_c>20
Max_hz8 102H Z
